WOOD LOUVRE 148-W
The top and bottom of the 148-W are planed, giving the louvre a Z-shaped profile. This allows the louvres to overlap to ensure no direct sunlight between the louvres.
The 148-W is a non-retractable louvre blind made of wood. The width of this louvre is 148 mm, the thickness 16 mm – at the rebates 7.5 mm. The 148-W louvre is suited for all kinds of internal and external installations; horizontal, vertical, and sloping. Even upside down. The blades of the blind can be either movable, or placed in a fixed position.
A WIDE VARIETY OF COLOURS AND TYPES OF WOOD
Western Red Cedar is an excellent choice for wooden louvres. It has a straight grain, is lightweight, stable and durable. Solar-Shield offers many kinds of colours and treatments for wood louvres. It is also possible to have louvres, rack arms and plastic components in distinguishing colours to achieve sophisticated architectural impressions. Custom made colours and structures are available on request.
TECHNICAL INFORMATION
PROFILE OF 148-W LOUVRE
The top and bottom of the 148-W are planed, giving the blade a Z-shaped profile. These rebates are 14 mm wide, and 8,5 mm deep, leaving a thickness of 7,5 mm.
148-W UNIQUE SHAPES
The 148-W can be applied in all kinds of blinds, and in a variety of unique shapes, such as; triangles, trapezia, and circles. Louvres from Sunshield are always customised. There is a solution for every situation. In many colours and in any desired shape.
148-W LOUVRE SYSTEM
The following image shows a schematic representation of an 148-W louvre system. Such a system consists of at least two rack arms, and a number of louvres, blades.
148-W louvre blades are moveable and can be placed in any position between 0 and 90 degrees. Our external louvre systems can be installed horizontal, vertical, in any desired slope, and upside down.
INFORMATION FOR ARCHITECTS & DESIGNERS
Talk to our team today and discover more about our external louvres.
Our team are on hand to answer any questions you may have about louvre applications, sizing and material choices.
